Part II: Configuring MTLS Client Authentication and Certificate-Bound Access Tokens in WSO2 Identity Server

Deploying and Configuring Mutual TLS Client Authenticator Artifacts

[[event_listener]]
id = "introspection_response_interceptor"
type = "org.wso2.carbon.identity.core.handler.AbstractIdentityHandler"
name="org.wso2.carbon.identity.oauth2.token.handler.clientauth.mutualtls.introspection.IntrospectionResponseInterceptor"
order=27
enable=true
[[event_listener]]
id = "is_introspection_data_provider"
type = "org.wso2.carbon.identity.core.handler.AbstractIdentityHandler"
name= "org.wso2.carbon.identity.oauth2.token.handler.clientauth.mutualtls.introspection.ISIntrospectionDataProvider"
order=28
enable=true
[oauth.grant_type.authorization_code]
grant_handler = "org.wso2.carbon.identity.oauth2.token.handler.clientauth.mutualtls.handlers.MTLSTokenBindingAuthorizationCodeGrantHandler"
[oauth.grant_type.client_credentials]
grant_handler = "org.wso2.carbon.identity.oauth2.token.handler.clientauth.mutualtls.handlers.MTLSTokenBindingClientCredentialsGrantHandler"
[oauth.grant_type.refresh_token]
grant_handler = "org.wso2.carbon.identity.oauth2.token.handler.clientauth.mutualtls.handlers.MTLSTokenBindingRefreshGrantHandler"
[oauth.grant_type.uma_ticket]
retrieve_uma_permission_info_through_introspection = true
[oauth.mutualtls]
client_certificate_header = "x-wso2-mtls-cert"

Testing the sample

openssl req -newkey rsa:2048 -x509 -keyout <CLIENT_PRIVATE_KEY> -out <CLIENT_PUBLIC_CERTIFICATE> -days <VALIDITY_PERIOD> -nodes
openssl req -newkey rsa:2048 -x509 -keyout key.pem -out client-certificate.pem -days 3650 -nodes
-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----
curl -X POST \
https://localhost:9443/oauth2/token \
-H 'content-type: application/x-www-form-urlencoded' \
-H '<CERTIFICATE_HEADER_NAME>: <CLIENT_PUBLIC_CERTIFICATE>' \
-d 'grant_type=client_credentials&client_id=<CLIENT_ID>'
curl -X POST \
https://localhost:9443/oauth2/token \
-H 'content-type: application/x-www-form-urlencoded' \
-H 'x-wso2-mtls-cert: -----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----' \
-d 'grant_type=client_credentials&client_id=h9gd1bLEgzUwftAhnrof0fZWcZwa'
{“access_token”:”9d109c6d-d42e-3b6e-9d93-ae3cb8f65ade”,”scope”:”default”,”token_type”:”Bearer”,”expires_in”:3445}
curl -X POST \
https://localhost:9443/oauth2/token \
-H 'content-type: application/x-www-form-urlencoded' \
-H '<CERTIFICATE_HEADER_NAME>: <CLIENT_PUBLIC_CERTIFICATE>' \
-d 'grant_type=authorization_code&client_id=<CLIENT_ID>&code=<CODE>&redirect_uri=http%3A%2F%2Flocalhost%3A8080%2Fplayground2%2Foauth2client'
curl -X POST \
https://localhost:9443/oauth2/token \
-H 'content-type: application/x-www-form-urlencoded' \
-H 'x-wso2-mtls-cert: -----BEGIN CERTIFICATE-----MIID3TCCAsWgAwIBAgIUJQW8iwYsAbyjc/oHti8DPLJH5ZcwDQYJKoZIhvcNAQELBQAwfjELMAkGA1UEBhMCU0wxEDAOBgNVBAgMB1dlc3Rlcm4xEDAOBgNVBAcMB0NvbG9tYm8xDTALBgNVBAoMBFdTTzIxDDAKBgNVBAsMA0lBTTENMAsGA1UEAwwER2FnYTEfMB0GCSqGSIb3DQEJARYQZ2FuZ2FuaUB3c28yLmNvbTAeFw0yMDAzMjQxMjQyMDFaFw0zMDAzMjIxMjQyMDFaMH4xCzAJBgNVBAYTAlNMMRAwDgYDVQQIDAdXZXN0ZXJuMRAwDgYDVQQHDAdDb2xvbWJvMQ0wCwYDVQQKDARXU08yMQwwCgYDVQQLDANJQU0xDTALBgNVBAMMBEdhZ2ExHzAdBgkqhkiG9w0BCQEWEGdhbmdhbmlAd3NvMi5jb20wggEiMA0GCSqGSIb3DQEBAQUAA4IBDwAwggEKAoIBAQC+reCEYOn2lnWgFsp0TF0R1wQiD9C/N+dnv4xCa0rFiu4njDzWR/8tYFl0koaxXoP0+oGnT07KlkA66q0ztwikLZXphLdCBbJ1hSmNvor48FuSb6DgqWixrUa2LHlpaaV7RvlmG+IhZEgKDXdS+/tK0hlcgRzENyOEdETDO5fFlKGGuwaGv6/w69h2LTKGu5nyDLF51rjQ18xp026btHC7se/XSlcp3X63xeOIcFv6m84AN2lnV+g8MOfu2wgWtsKaxn4BL64E7nHZNNLxMRf7GtUm2bl9ydFX4aD1r1Oj4iqFWMNcfQ676Qshk8s7ui3LKWFXwNN/SRD0c/ORtv23AgMBAAGjUzBRMB0GA1UdDgQWBBRDu/vqRafReh4fFHS3Nz4T6u9mUDAfBgNVHSMEGDAWgBRDu/vqRafReh4fFHS3Nz4T6u9mUDAPBgNVHRMBAf8EBTADAQH/MA0GCSqGSIb3DQEBCwUAA4IBAQB7NH51Yj4moEhMonnLUh3eTtf6DUnrpscx6td28rryoDZPfCkJs4VHU9F50etw54FoHqoIaHp5UIB6l1OsVXytUmwrdxbqW7nfOItYwN1yV093aI2aOeMQYmS+vrPkSkxySP6+wGCWe4gfMgpr6iu9xiWLpnILw5q71gmXWtS900S5aLbllGYe74jkyldLIdhS4TyEBIDgcpZrD8x/Z42al6T/6EANMpvu4Jopisg+uwwkEGSM1I/kjiW+YkWC4oTZ1jMZUWC11WbcouLwjfaf6gt4zWitYCP0r0fLGk4bSJfUFsnJNu6vDhx60TbRhIh9P2jxkmgNYPuAxFtF8v+h-----END CERTIFICATE-----' \
-d 'grant_type=authorization_code&client_id=h9gd1bLEgzUwftAhnrof0fZWcZwa&code=d7678fec-2cb0-374b-82cb-d368d301be57&redirect_uri=http%3A%2F%2Flocalhost%3A8080%2Fplayground2%2Foauth2client'
{"access_token":"72480539-a018-3611-aeb3-1e3e8b7f78da","refresh_token":"47757b20-1013-3fd7-a547-c8b080427abd","scope":"openid","id_token":"eyJ4NXQiOiJaalJtWVRNd05USmpPV1U1TW1Jek1qZ3pOREkzWTJJeU1tSXlZMkV6TWpkaFpqVmlNamMwWmciLCJraWQiOiJaalJtWVRNd05USmpPV1U1TW1Jek1qZ3pOREkzWTJJeU1tSXlZMkV6TWpkaFpqVmlNamMwWmdfUlMyNTYiLCJhbGciOiJSUzI1NiJ9.eyJhdF9oYXNoIjoiZXgyci1tZGhhRXJoT0MxSjlUTjZXQSIsImF1ZCI6Img5Z2QxYkxFZ3pVd2Z0QWhucm9mMGZaV2Nad2EiLCJjX2hhc2giOiI3bnlHb0Y5b0NuRFdIWk9uZlVuT3VnIiwic3ViIjoiYWRtaW4iLCJuYmYiOjE1ODY4OTA3MTYsImF6cCI6Img5Z2QxYkxFZ3pVd2Z0QWhucm9mMGZaV2Nad2EiLCJhbXIiOlsiQmFzaWNBdXRoZW50aWNhdG9yIl0sImlzcyI6Imh0dHBzOlwvXC9sb2NhbGhvc3Q6OTQ0M1wvb2F1dGgyXC90b2tlbiIsImV4cCI6MTU4Njg5NDMxNiwiaWF0IjoxNTg2ODkwNzE2LCJzaWQiOiIwMTQxOGNiYS1kZWMxLTRjY2UtODg1MC0yM2Q5YWVmNDdhMjUifQ.c7zueSgckyK7la0fWCVXsDL7zEQV40VmI2FUCDrlN4sFY3U90ObtwXVp0V6Di_BzOWCGc7RN6xWTBkfo2ayph8FxVtUyO-c4tUZCB_EDCsyOLBjV-s1Z7bhy4lw5-utSCcE5d4TZoDTFKvL7PrUCrRZ2VcGfmqNKZKgRo1eCfVcT5M7Udzkq22JdOp1jkv0tTso3zvQFqUKFaNNi1gKDdWR00WjBEnAMhmbz0Sd2HZ2GNuKbwYZLPz3P2FZvS7mVJJW_kku4nTksP3cMIrDjZz8fCST210GmlW_GC1f2XudhiM8Qkdcu011cdEmG5bmJcWCQs-90GLn5u-e1gjIaQw","token_type":"Bearer","expires_in":3600}
curl -X POST \
https://localhost:9443/oauth2/token \
-H 'content-type: application/x-www-form-urlencoded' \
-H '<CERTIFICATE_HEADER_NAME>: <CLIENT_PUBLIC_CERTIFICATE>' \
-d 'grant_type=refresh_token&refresh_token=<REFRESH_TOKEN>&client_id=<CLIENT_ID>'
curl -X POST \
https://localhost:9443/oauth2/token \
-H 'content-type: application/x-www-form-urlencoded' \
-H 'x-wso2-mtls-cert: -----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----' \
-d 'grant_type=refresh_token&refresh_token=47757b20-1013-3fd7-a547-c8b080427abd&client_id=h9gd1bLEgzUwftAhnrof0fZWcZwa'
{"access_token":"e01612d2-5538-32ac-9b1c-c2978ce47e91","refresh_token":"0278af3e-e75b-3f66-bad5-13a773397b8e","scope":"openid","id_token":"eyJ4NXQiOiJaalJtWVRNd05USmpPV1U1TW1Jek1qZ3pOREkzWTJJeU1tSXlZMkV6TWpkaFpqVmlNamMwWmciLCJraWQiOiJaalJtWVRNd05USmpPV1U1TW1Jek1qZ3pOREkzWTJJeU1tSXlZMkV6TWpkaFpqVmlNamMwWmdfUlMyNTYiLCJhbGciOiJSUzI1NiJ9.eyJhdF9oYXNoIjoiSHJsTl9PNGZ3THNldnlRWXcxdjdGdyIsImF1ZCI6Img5Z2QxYkxFZ3pVd2Z0QWhucm9mMGZaV2Nad2EiLCJzdWIiOiJhZG1pbiIsIm5iZiI6MTU4Njg5MTU4MywiYXpwIjoiaDlnZDFiTEVnelV3ZnRBaG5yb2YwZlpXY1p3YSIsImFtciI6WyJyZWZyZXNoX3Rva2VuIl0sImlzcyI6Imh0dHBzOlwvXC9sb2NhbGhvc3Q6OTQ0M1wvb2F1dGgyXC90b2tlbiIsImV4cCI6MTU4Njg5NTE4MywiaWF0IjoxNTg2ODkxNTgzfQ.XonQryWAEoUAsEWBYh97N8Wra1o1g-gs_VQfD1jeKpIMXONrRJt9ArTwf7THE0AmwoiHqv3JDsFDfj7FY4-xMEXb9bbwm2CB7ptWdw_Z0_rEoLv8uFo69k0G07C1bPsE4Lfdg4_BKMWN5-h8U0l7p35AQW-hT4qGkASOkgo0xz2AaBpXgItP91NsUoJ3Xmr1E9Bmv_0vIO8XK1hvZkk95inCVp2HVBBRuQNIO4PIaqrGNijMUoKN5DokUr_pyZ3xHbHL8pJ5Smg5wLfDAng7BSwiBd1Lf_8wyWaNSHCvI27sVtU8fLRi7X0_p-4mVtmfK2Qe-hK8wQA3E_vFLr3WMA","token_type":"Bearer","expires_in":3600}
curl -X POST \
https://localhost:9443/oauth2/introspect \
-H 'authorization: Basic YWRtaW46YWRtaW4=' \
-H 'content-type: application/x-www-form-urlencoded' \
-d token=9d109c6d-d42e-3b6e-9d93-ae3cb8f65ade
curl -X POST \
https://localhost:9443/oauth2/introspect \
-H 'authorization: Basic YWRtaW46YWRtaW4=' \
-H 'content-type: application/x-www-form-urlencoded' \
-d token=9d109c6d-d42e-3b6e-9d93-ae3cb8f65ade
{
"nbf": 1586929210,
"scope": "openid",
"active": true,
"cnf": {
"x5t#SHA256": "mt3KDY1hofQurloTbphKHCSrTlAGl5MlgXX6Xxj9c_E"
},
"token_type": "Bearer",
"exp": 1586932810,
"iat": 1586929210,
"client_id": "h9gd1bLEgzUwftAhnrof0fZWcZwa",
"username": "admin@carbon.super"
}

--

--

--
